Reclaim Energy Air-Source Heat Pump Hot Water System

Reclaim Energy Air-Source Heat Pump Hot Water System

Starts from $4891.00

The Reclaim Energy Air-Source CO2 Heat Pump Hot Water System offers unparalleled energy efficiency, allowing you to save up to 80% on your hot water bill. With a smart independent controller and flexible operational modes, this system integrates seamlessly with your home’s PV system, ensuring optimal energy use and cost savings. Available in glass-lined and stainless-steel tank options ranging from 160L to 400L, this system is perfect for sustainable, off-grid living.

Reclaim Energy

Product Data Sheet

Warranty Information
  • Energy Efficient: Save up to 80% on your hot water bill with advanced CO2 heat pump technology.
  • Smart Control: Choose from 6 operational modes to optimize energy use according to your needs.
  • PV Integration: Seamlessly integrates with your home’s photovoltaic system for enhanced energy management.
  • Flexible Tank Options: Available in both glass-lined and stainless-steel tanks with capacities ranging from 160L to 400L.
  • Silent Operation: Ultra-quiet operation with noise levels as low as 37 dB.
  • Robust Warranty: Benefit from extensive warranty coverage, including up to 15 years on stainless steel tanks.
  • Environmentally Friendly: Uses CO2 refrigerant, which has minimal environmental impact compared to traditional refrigerants.

Specifications

  • Available Tank Capacities: 160L, 250L, 315L, 400L
  • Tank Options: Glass Lined (GL), Stainless Steel (SS)
  • Heat Pump Model: HE-UM60AR
  • Heat Output: 5.06 kW (at 32.5°C ambient / 21.0°C cold water inlet)
  • Power Input: 0.83 kW (at 32.5°C ambient / 21.0°C cold water inlet)
  • Coefficient of Performance (COP): 6.09 (at 32.5°C ambient / 21.0°C cold water inlet)
  • Operating Ambient Temperature Range: -10 to 43°C
  • Heat Pump Refrigerant: CO2 (R744)
  • Hot Water Delivery Temperature: 63-67°C (variable based on heat pump inlet temperature)
  • Standby Power Consumption: 5.05 W
  • Noise Level: 37 dB
  • Dimensions (H x W x D): 672 x 799 x 299 mm
  • PTRV Rating: 850 kPa (Glass Lined); 700 kPa (Stainless Steel)
  • Controller Warranty: 7 years (Non-Wi-Fi), 8 years (Wi-Fi)
  • Tank Warranty: 10 years (Glass Lined), 15 years (Stainless Steel)
