SolarEdge EV Charger 1PH 7.4kW

SolarEdge EV Charger

Starts from $1855.00

The SolarEdge EV Charger 1PH 7.4kW is a Wi-Fi-enabled, level 2 charger offering 32A fast charging. Seamlessly integrating with SolarEdge systems, it optimizes solar energy use, supports indoor and outdoor installation, and provides smart scheduling and remote control via the mySolarEdge app for efficient EV charging.

SOLARDEGE

Product Data Sheet

Warranty Information
  • Smart Charging: Optimized for use with SolarEdge inverters, allowing up to 100% renewable energy usage.
  • Remote Control: Monitor and control your charging via the mySolarEdge mobile app, including smart scheduling.
  • Flexible Installation: Rated for both indoor and outdoor use with a durable IP54 protection rating.
  • High Power Output: Provides up to 7.4kW of charging power, enabling quick and efficient charging.
  • Seamless Integration: Synchronizes with the full SolarEdge ecosystem, including PV, home backup, and smart home devices.

Specifications

  • Charging Mode: AC Level 2 / Mode 3
  • Rated AC Power Output: 7.4 kW
  • Maximum Input/Output Current: 32A @ 230Vac
  • Nominal AC Output Voltage: 230Vac
  • Nominal AC Frequency: 50/60 Hz
  • EV Connector: IEC 62196 Type 2
  • Cable Length: 7.6 m
  • Weight: 2.85 kg (charger unit), 5.7 kg (with cable)
  • Dimensions: 309 x 190 x 154 mm
  • Protection Rating: IP54 (connected to EV or with dust cap)
  • Operating Temperature Range: -30°C to +50°C
  • Communication Interfaces: Wi-Fi, Ethernet, RS485, optional Cellular
  • Compliance: IEC 61851-1, IEC 61851-21-2
